Image Sensor |
MIS2058(AHD 1080P) |
GC2053(AHD 1080P) |
|
Sensor Size |
1/2.9¡± |
1/2.9¡± |
|
Effective Pixels |
1920*1080 |
1920*1080 |
|
Resolution |
1000TVL |
1000TVL |
|
View Angle |
110¡ã/65¡ã/170¡ã |
110¡ã/65¡ã/170¡ã |
|
TV System |
PAL/NTSC |
PAL/NTSC |
|
Minimum Illumination |
0.001Lux |
0.001Lux |
|
Working Current |
130mA |
130mA |
|
Scanning System |
525lines, 60 fields/sec |
|
|
Electric Shutter |
1/60~1/100000 seconds |
|
|
Frame Frequency |
25/30fps |
|
|
Working Voltage |
DC 12V |
|
|
Working Voltage Range |
DC 12V~24V |
|
|
Operating Temperature |
-20¡æ~+70¡æ |
|
|
Storage Temperature |
-40¡æ~+80¡æ |
|
|
Waterproof Grade |
IP68(Lens only) |
|
|
Whole Set Included |
1*Camera 1*DC power cable 1*Video cable 1*User¡¯s manual 1*Package box |
|
